GIGAVAC P105CDA MiniTACTOR DC-Contactor
1200VDC, 50A, 24VDC, No Contact (Sensata Gigavac P105CDA MiniTACTOR DC-Contactor)
| Manufacturer | |
|---|---|
| Product Category | |
| Model | |
| Current Rating | |
| Contact Voltage (Operating Max) | |
| Coil Voltage |
- 12 months manufacturer warranty
- FREE SHIPPING FOR ORDERS ABOVE $999
Â
$81.65
Availability: 138 in stock (can be backordered)
Technical Information
Sensata Gigavac P105CDA MiniTACTOR DC-Contactor features a small, lightweight, and cost-effective patented design for use in various applications. The contactors provide a hermetically sealed chamber to ensure a clean switching environment and a bi-directional switching capability, and can easily be installed on a panel in any orientation according to the application. The Gigavac P105CDA MiniTACTOR DC-Contactors achieve make and break power switching of up to 1500VDC and a continuous current capacity of up to 80A. This Gigavac P Series MiniTACTOR Power Contactors deliver RoHS2-compliant and CE-certified models, and comply with NEC 690.11 and NEC 690.12 solar energy requirements.
Gigavac P105CDA MiniTACTOR DC-Contactor can used in:
- Precharge circuits
- Battery chargers.
- Solar energy applications
FEATURES
- Small, lightweight, and cost-effective patented design
- Hermetic seal ensures a clean, consistent contact environment
- RoHS2 compliant
- Make / Break switching to 1200Vdc
- Can be installed in any position
- Capable of bi-directional switching
- Perfect choice for pre-charge, charge, and solar applications
TECHNICAL SPECIFICATIONS
| Product Type | DC-Contactors, Electromechanical | |||||||
| Product Series | P105 | |||||||
| Contact Current Rating | 50 Amps | |||||||
| Switching Voltage | 1200 VDC | |||||||
| Coil Voltage | 24 VDC | |||||||
| Contactor/Coil Type | DC Type | |||||||
| Coil Current | 85 mA | |||||||
| Mechanical Life | 1,000,000 Cycles | |||||||
| Termination Style | Stud | |||||||
| Contactor Contact Form | 1 Form X (SPST-NO-DM) | |||||||
| Features | Hermetic Sealed | |||||||
| Operating Temperature | -40°C ~ 65°C | |||||||
| IP Rating | IP69K | |||||||
| Mounting Technique | Chassis Mount | |||||||
| Operate Time | 25 ms | |||||||
| Release Time | 8 ms | |||||||
Export and Environmental Classification
| Manufacturer | SENSATA / GIGAVAC |
| Classification | HV Relay, DC Contactor |
| RoHS Compliant | Compliant  |
| ECCN | EAR99 |
| HS CODE | 853590.0089 |
| Contactor Height | 45.97 mm |
| Contactor Length | 78.74 mm |
| Contactor Width | 30.23 mm |
| Contactor Weight | 112 Gr |
| Standard Pack Size | 60 Pcs |
| Datasheet |  Click to Download |
